Specifications
Dimensions
Operating height, max std. bucket 105 in
Hinge pin height, max 83 in
Overall height of machine 57 in
Overall length of machine, std. bucket 105 in
Overall length of loader, no attachment 86 in
Wheelbase/track length 43 in
Machine width
Max, w/9-in (230-mm) tracks 42 in
Min, w/7-in (180-mm) tracks 36 in
Ground clearance, min
Center 8.9 in 226 mm
Side 3.7 in 94 mm
Power
Engine Kubota® D1105
Fuel Diesel
Number of cylinders 3
Displacement 68.5 in
Bore 3.07 in
Stroke 3.09 in
Gross power rating (SAE J1995) 24.8 hp
Rated speed 3,000 rpm
Performance
Operating height, max std. bucket 105 in
Hinge pin height, max 83 in
Overall height of machine 57 in
Overall length of machine, std. bucket 105 in
Overall length of loader, no attachment 86 in
Wheelbase/track length 43 in
Machine width
Max, w/9-in (230-mm) tracks 42 in
Min, w/7-in (180-mm) tracks 36 in
Ground clearance, min
Center 8.9 in
Side 3.7 in
Fluid Capacities
Hydraulic reservoir capacity 9.2 gal
Engine oil, w/filter 5 qt
Fuel tank capacity 10.5 gal
